11. Remove the upper side connector (Engine
connector) by rotating its lever to upside.
12. Remove the downside connector (vehicle
connector) by rotating its lever to upside.
NOTE
1. We cannot remove the vehicle connector
before removing the 'Engine Connector'.
2. It is Poka-yoke that these connector cannot
be fitted into their interchanged locations.
Intallations:
1. Fit the downside connector (vehicle connector)
and lock it by rotating lever to downside.
2. Fit the upper side connector (Engine
connector) and lock it by rotating lever to
downside.
3. Fit the bracket and tighten the bolts by ratchet
and socket as per specified torque.
