DRIVETRAIN

355

DRIVETRAIN

B. INPUT SHAFT

SR NO. DESCRIPTION

1 BALL BEARING (I/S FRT. END)

2 INPUT SHAFT

3 THIRD GEAR WHEEL

4 CIRCLIP (SELECTIVE)

5 SYNCHRO CONE

6 ENGAGING GEAR (SINT SOFT VERSION)

7 SPRING (SYNCHRO) - 3 NOS.

8 BALL 5.556DIA-GRADE 20 IS2898 - 3 NOS.

9 CARRIER - 3 NOS.

10 SHIFTER SLEEVE (3RD/4TH SPEED)

11 FOURTH GEAR WHEEL

12 SPACER INPUT SHAFT

13 DEEP GROOVE BALL BRG WITH SNAP RING

14 SNAP RING (SELECTIVE)
