GENERAL
13
GENERAL
1.3 LIFTING, JACKING, TOWING POINTS
Using The Two Post Lift:
When using a 2 post lift to raise the vehicle for
servicing, always follow these points:
• Observe the hoist manufacturer’s rating, safety
precautions, and usage guidelines.
• Make sure the hoist contacts the appropriate
lift points on the vehicle undercarriage.
• Balance the vehicle properly on the lift arms.
• Once the lift raises the vehicle to the desired
position, lockout the hoist arms to prevent
movement.
Following fig. shows the front and the rear jacking
points by two post lift
WARNING
• Do not raise the hoist unless the vehicle is
properly balanced on the lift arms. The vehicle
may fall, causing severe injury, death or damage
the vehicle.
• Do not allow the lift arms to contact the vehicle
fuel or brake lines, engine oil pan, fuel tank, or
other parts susceptible to damage from the
vehicle’s weight during lifting.
Front Jacking Points
Rear Jacking Points
