NANO

810

BODY

Installation

1. Mount floor carpet on body shell and fix all tree

clips.

2. Refit rear seats. (Refer Rear Seat installation

procedure)

3. Tighten four bolts of gear shifter housing.

4. Connect gear shifting and selector cable. Fix two

omega clips.

5. Refit centre console. (Refer Centre Console

installation procedure)

6. Refit parking brake lever. (Refer ParkingBrake Lever

installation procedure)

7. Connect parking brake cable.

8. Refit front seat along with seat mounting bracket

and tighten all bolts.

9. Refit front seat belt buckle bolts.

10.Fix B-Pillar trim.

11. Remove four mounting bolts and take out gear

shifter housing.

12.Disengage parking brake cable and remove parking

brake lever. (Refer Parking Brake Lever removal

procedure/Brakes)

13.Remove the bolt of front seat belt buckle.

14.Remove rear seats. (Refer Rear Seat removal

procedure)

15.Remove all tree clips and take out floor carpet.
