BODY

FLOOR CARPET

Removal

1. Remove three screws securing side panel to the

driver’s seat. (Repeat same procedure for co-driver

side)

2. Remove two bolts securing seat mounting bracket

to the body.

3. Remove the centre bolt securing seat mounting

bracket to the body.

Installation

1. Fix roof trim on to the roof using the adhesive

(Headliner adhesive WC - 2446)

2. Fit all tree clips on to the roof trim.

3. Connect the electrical connector of roof mounted

stop lamp and fit stop lamp.

4. Fit reading lamp and both sun visors.

6. Remove six tree clips and take out roof trim .

7. Take out roof trim
