DRIVETRAIN
F. TOP COVER ASSEMBLY
SR NO. DESCRIPTION
01 TOP COVER
02 BUSH (SELECTOR SHIFTER SHAFT)
03 OIL SEAL (SEL SHIFT SHAFT)
04 ASSY SELECTOR SHIFTER SHAFT
05 DUST CAP
06 EXT.CIRCLIP 15X1N-IS3075P1-SS8400
07 SPACER - SELECTOR / SHIFTER SHAFT
08 SPRING (1ST & 2ND SELECTION)
09 SPRING ( REV. SELECTION )
10 CUP (SELECTOR SHIFTER SHAFT)
11 PLATE TOP COVER
12 HEX FL SCR M6X10 TS17130-8.8-SS8451S2-Y
13 SPACER SELECTOR SHIFTER SHAFT
14 CIRCLIP E 12X1.3 IS3075 PT3 SS8400
15 INTERLOCK PIECE
16 BARREL (CENTRAL DETENT)
SR NO.
DESCRIPTION
17 SPRING OUTER ( CENTRAL DETENT )
18 CENTRAL DETENT
19 FINGER (SELECTION SHIFTING)
20 SPIRAL PIN (6X28)
21 BELLOW SELECTOR SHIFTER
22 COLLER WASHER (DELRIN)
23 SUBASSY BELL CRANK LEVER (SELECTION)
24 PIN ( ASSY TOP COVER TO SEL. LEVER)
25 HEX FL NUT AM8 TS17430-8-SS8451S2-Y
26 ASSY. OIL FILLER PLUG CUM BREATHER
26-a OIL FILLER PLUG CUM BREATHER
26-b BREATHER CAP
27 HEX FL BOLT M8X25 TS17130-8.8-SS8451S2-Y
28 BRACKET (CABLE ANCHORING)
29 HEX FL SCREWM8X18 TS17130-8.8-SS8451-8C
