ENGINE 273 MPFI

5. Torque 7 Kg-m to all bolts as per sequence

•

Fit water bypass tube.

•

Fit intake manifold along with throttle body.

•

Fit exhaust manifold.

Cylinder Head Cover Assembly:

•

Place the baffle plate gasket in cylinder head cover.

•

Place baffle plate on baffle plate gasket.

•

Tighten the mounting screws of baffle plate.

•

Place the cylinder head cover gasket and fix the

cylinder head cover.

•

Fit the oil filler cap alongwith gasket.
