Fix the end bead at the lower end of the glass. End
bead should not come out of the glass edge. Start
the end beading fixing approximately from any gap
between the edges of end bead.
Clean the glass and painted surface with the
cleaner TEROSTAT – 8550. Allow it to dry
completely.
Apply a thin and even coat
(approximately 0.5mm
thick)
of PRIMER TEROSTAT-8511 on the glass.
Allow it to dry for 2 minutes.
Apply thin and even coat
(approximately 0.5mm
thick) of
PRIMER TEROSTAT- 8521 on painted
surface. Allow it to dry for 2 minutes.
Apply sealant TEROSTAT-8590 on the glass with
the applicator nozzle.
Mount the glass on the body flange within 20
minutes. Wipe of the excessive spill off with clean
dry rags. Do not use ISOPROPANOL.
Keep it position for minimum 30 minutes.
Do not drive the vehicle for 2Hrs.
REAR QUARTER GLASS
REMOVAL
1. Remove rear quarter trim.
(For procedure refer
rear quarter trim removal procedure in this
section)
2. Remove “D” pillar trim.
(For procedure refer “D”
pillar trim removal procedure in this section)
3. Remove “C” pillar trim.
(For procedure refer “C”
pillar trim removal procedure in this section)
4. Cut the sealant with a thin sharp blade from the
inside.
! CAUTION
Do not damage the embossed rear demister lines
.
