1014 / 1575
ELECTRICAL
194
8.14.6. TELL TALES MATRIX:
PRE-CHECK
SR.
NO
TELL
TALES
COLOUR
SYMBOL
Cluster
Other
TEXT ON
DISPLAY
WITH
PRIORITY
DIESEL 2.2L
( KMPH )
1
Turn Left
Green
X
X
X
√
2
Turn Right
Green
X
X
X
√
3
High Beam
Blue
X
X
X
√
4
Battery
Charging
Red
X
√
X
√
Park Brake
Applied
Park brake
ON(
H
)
√
5
Brake Fluid
Oil level low
Red
√
X
Brake Fluid
LOW(
H
)
√
6
Diesel Pre-
Heat
Amber
√
X
X
√
8
Malfunction
Indication
lamp
Amber
√
X
X
√
9
Low Engine
Oil Pressure
Red
X
√
X
√
10
Water In
Fuel (
Diesel,
DICOR
)
Amber
√
X
X
√
11
ABS
Amber
√
X
X
√
12
Airbag
Red
X
√
X
√
13
Seat Belt
Red
√
X
FASTEN SEAT
BELT (
H
)
√
14
Immobilizer
Red
X
X
X
√
15
Front Fog
Green
X
X
X
√
16
Rear Fog
Amber
X
X
X
√
17
Door open
Red
X
X
X
√
Green
X
X
X
√
18
Transfer
Mode
Green
X
X
X
√
