AIR CONDITIONING
29
B. BLOWER SPEED REGULATION KNOB:
The ventilation system has a four speed blower.
The blower speeds can be regulated to any one of
the following speeds by operating the knob at the
centre of the control panel (B).
LOW l MEDIUM l HIGH l VERY
HIGH
C. AIR DIRECTION CONTROL KNOB:
The air flow can be changed by turning the switch
to the desired direction (C)
Towards face
Towards face and feet
Towards feet
Towards feet and windshield
Recommended for clearing fogging on windshield)
Air demist / defrost windshield
(Recommended for clearing heavy fog and snow)
D. A. C. ON/OFF SWITCH
The A. C. can be switched on by pressing the
switch (D) on the A. C. control panel provided the
blower is ‘ON’ and the engine is running. The
indicator lamp will show that the A. C. is ‘ON’.
(In heater version: This is absent and a dummy
knob (D) is provided on control panel).
E. FRESH AIR SWITCH
Fresh air can be circulated by pressing switch (E)
on the panel. This should be put on only when
discomfort is felt, as cooling effect reduces with
fresh air entry.
NOTE:
The A.C. can be switched ‘ON’ only if the blower
is ON’. Engine fast idling control has been
provided. When the AC is switched ‘ON’ the
engine idling RPM increases marginally to adjust
to the A.C. compressor load. When the thermostat
cuts off the A.C. engine idling RPM decreases to
normal idling. The condenser fan is a two speed
fan.
NOTE:
If your car is has been left in the sun with the
windows closed, to quicken the cooling open the
windows briefly while you operate the air
conditioner with the air circulation switch in fresh
air mode and the fan at a higher speed.
MAXIMUM COOLING EFFECT:
Switch ‘ON’ the A.C. and keep the blower at
maximum speed. Keep air direction in face mode
.All vents should be opened completely. Keep the
air circulation switch in the recirculation mode and
temperature control switch in the maximum
cooling (Blue) position.
FRONT WINDSHIELD DEMISTER / DEFROST:
First start the engine and accelerate to warm up
Select defrost / demist mode on air flow direction
control. Then set the blower to maximum speed
and temperature control knob to maximum heat.
These settings direct all air flow to the base of the
front windshield and towards front door glasses.
The hot air clears the mist frost from the
windshield and door glasses. Electrical heater coil
is provided for demisting of tail gate glass for
deluxe models.
NOTE:
Refrigerant charged in the air conditioning circuit
has been identified on the label over hood inner
panel. Use only refrigerant as given in the label for
topping
up or recharge, i.e. do not charge R 12
(CFC) in the vehicle earlier charged with R 134a
Non CFC) or vice versa.
REMOVAL AND REFITMENT OF HVAC UNIT:
For removal and refitment of HVAC unit, refer
body group cockpit section
