SRS
24
10.8 SRS ECU DTC CODES
B0001-1A
Driver Frontal Stage 1 Deployment Control circuit resistance below threshold
B0001-1B
Driver Frontal Stage 1 Deployment Control circuit resistance above threshold
B0001-2B
Driver Frontal Stage 1 Deployment Control signal cross coupled
B0001-11
Driver Frontal Stage 1 Deployment Control circuit short to ground
B0001-12
Driver Frontal Stage 1 Deployment Control circuit short to battery
B0010-1A
Passenger Frontal Stage 1 Deployment Control circuit resistance below threshold
B0010-1B
Passenger Frontal Stage 1 Deployment Control circuit resistance above threshold
B0010-2B
Passenger Frontal Stage 1 Deployment Control signal cross coupled
B0010-11
Passenger Frontal Stage 1 Deployment Control circuit short to ground
B0010-12
Passenger Frontal Stage 1 Deployment Control circuit short to battery
B0070-1A
Driver Seatbelt Pretensioner Deployment Control circuit resistance below threshold
B0070-1B Driver Seatbelt Pretensioner Deployment Control circuit resistance above threshold
B0070-2B
Driver Seatbelt Pretensioner Deployment Control signal cross coupled
B0070-11
Driver Seatbelt Pretensioner Deployment Control circuit short to ground
B0070-12
Driver Seatbelt Pretensioner Deployment Control short to battery
B0072-1A
Passenger Seatbelt Pretensioner Deployment Control circuit resistance below threshold
B0072-1B
Passenger Seatbelt Pretensioner Deployment Control circuit resistance above threshold
B0072-2B
Passenger Seatbelt Pretensioner Deployment Control signal cross coupled
B0072-11
Passenger Seatbelt Pretensioner Deployment Control circuit short to ground
B0072-12
Passenger Seatbelt Pretensioner Deployment Control short to battery
B100E-2B
Frontal Impact Driver sensor signal cross coupled
B100E-4A
Frontal Impact Driver sensor incorrect component installed
B100E-86 Driver Frontal Impact Driver sensor signal invalid
B100E-11
Frontal Impact Driver sensor circuit short to ground
B100E-12
Frontal Impact Driver sensor circuit short to battery
B100E-64 Frontal Impact Driver sensor Signal Plausibility failure
B100E-96
Frontal Impact Driver sensor component internal failure
B100F-2B Frontal Impact Passenger sensor signal cross coupled
B100F-4A Frontal Impact Passenger sensor incorrect component installed
B100F-86 Driver Frontal Impact Passenger sensor signal invalid
B100F-11
Frontal Impact Passenger sensor circuit short to ground
B100F-12
Frontal Impact Passenger sensor circuit short to battery
B100F-64 Frontal Impact Passenger sensor Signal Plausibility failure
B100F-96 Frontal Impact Passenger sensor component internal failure
U1006-43
Control Module Internal special memory failure
U1006-49 Control Module Internal electronic failure
U3006-16 Control Module Input Power "A" circuit voltage below threshold
U3006-17 Control Module Input Power "A" circuit voltage above threshold
B1011-00
Front Deployment Crash no sub type information
B1012-00
Belt Pretensioner Deployment Crash no sub type information
