DRIVETRAIN-TA65 Star
30
ITEM NO.
DESCRIPTION
01
TA65* COMP;BOLT FL/ MANZA CS (WITH VSS)
02
HOUSING (FRONT HALF)
03
HOUSING;REAR HALF
04
CYL.PIN (HSG.FRT.HALF TO HSG.REAR HALF)
05
INPUTSHAFT COVER
06
OIL SEAL (INPUT SHAFT);CR INDIA
06
OIL SEAL (INPUTSHAFT) FENNER
06
"OFFER DRG" OIL SEAL (INPUT SHAFT)
06
OIL SEAL (INPUT SHAFT) CR
06
OIL SEAL (INPUT SHAFT) (M/S SIGMA NOK)
07
HEX SCREW M6X10 TS17070-8.8-SS8451S2-Y
08
ASSY.REVERSE LEVER
09
BARREL REVERSE DETENT
10
BRACKET REV.LEVER
11
PIVOT PIN (REVERSE LEVER)
12
"OFFER DRG" OIL SEAL (DRIVE SHAFT)
12
OIL SEAL(DRIVE SHAFT)WITH DUST LIP;SIGMAN
12
OIL SEAL (DRIVE SHAFT) WITH DUST LIP;CR
13
HEX FL NUT BM8 TS17430 10 SS8451S2-YH
14
HEX FL SCR M8X22 TS17070-8.8-SS8451S2-Y
15
SPRING (REVERSE INHIBITOR)
16
BALL 8 DIA GRADE-20 IS2898
17
SOCKET HEAD CAP SCREW
18
CYL PIN 6m6X12 IS 2393
19
SUB ASSY INTERLOCK PIN
20
PIN (INHIBITOR)
21
FINGER REVERSE INHIBITOR
22
SPACER (INHIBITOR)
23
SPACER (INHIBITOR OUTER)
24
HEX FL NUT AM6 TS17430-8-SS8451S2-Y
25
SEALING WASHER 16X22 IS3175 CU
26
MAGNETIC DRAIN PLUG
27
FILLER PLUG
28
SEALING WASHER 8X14 IS3175 CU
30
SEALING WASHER 10X13.5 IS3175 AL
31
OIL CHANNEL
32
HEX FL BOLT M8X38 TS17070-8.8-SS8451S2-Y
33
REVERSE LIGHT SWITCH (OFFER)
33
ASSY_REVERSE_LIGHT_SWITCH_M/S_JAY_SWITCHES
33
REVERSE LIGHT SW (REV) - M/S. MINDARIKA
33
REVERSE LIGHT SWITCH --M s SRICHARAN
33
REVERSE LIGHT SWITCH M/S PMP
33
REVERSE LAMP SWITCH M/S MINDARIKA MAKE
33
REVERSE LIGHT SW.-SHUTHAM
33
REVERSE LIGHT SWITCH- PECO
36
H/FL BOLT M8X55 TS17070-10.9 SS8451S2-YH
37
ASSY.REAR COVER
