DRIVETRAIN-TA65 Star
5
5.2. B. TRANSAXLE (REVOTRON)
TECHNICAL SPECIFICATIONS:
Type
Synchromesh on all forward gears and sliding mesh for reverse gear.
Oil capacity
1.8 Liters
Type of oil
SAE 75W/90, GL4 (for Export), 80EP (For Domestic)
Model
Gear Ratios
TA 65-5*
REVOTRON
1st - 3.64
2nd - 1.95
3rd - 1.27
4th - 0.88
5th - 0.714
REV. - 3.58
Final Drive Ratios
3.765
Gear Shift
Cable operated floor mounted with international “H” pattern with fifth and
reverse inline.
TIGHTENING TORQUES:
SR. NO.
DESCRIPTION
TORQUE (Kg-m)
1
Engine ‘A’ mount nut
2.5
2
Engine ‘A’ mount bracket to block
4
3
Engine ‘B’ mount nut
6
4
Engine ‘C’ mount nut
4
5
Engine ‘C’ mount to body shell
8
6
Starter motor mounting
2.4
7
Fuel Line Clamps
1.5
8
Transaxle mounting bolt
4
9
Top cover Mounting Bolts
2.1 to 2.5
10
Lay shaft and input shaft nuts
12.3 to 16.7
11
Rear cover mounting screws
2.1 to 2.5
12
Drain plug and filler plug
3 to 4.1
13
Rear cover Assy mounting bolts
2.1 to 2.5
14
Front and Rear Half Housing bolts
2.1 to 2.5
15
Reverse Lever Bracket Mounting bolts
2.1 to 2.5
