DRIVETRAIN-TA65 Star
2
5.2. SPECIFICATIONS AND TIGHTENING TORQUES
5.2. A. CLUTCH
TECHNICAL SPECIFICATIONS:
Type Diesel
REVOTRON
Cover Assembly
Disc Assembly
Release bearing Assembly
Single disc dry friction
Diaphragm spring type
Pre-damper X (C) type
Non-asbestos (F810 DS) facings
Self-Centering Type
Clutch Disc :
(Refer Fig. 1)
REVOTRON
1. Outer Diameter
2. Inside Diameter
3. Thickness of Clutch disc with new lining under
380 kg load
4. Max. Permissible imbalance of clutch disc
5. Cushioning of Clutch disc
6. Total Friction Area (Both sides)
200 mm
134 mm
7 + 0.3 mm
30 gm-cm
0.6 to 0.9 mm
346 sq. cm
TIGHTENING TORQUES:
Clutch Housing to Cylinder block
Clutch Pressure plate mounting bolts
4 to s6 mkg.
2.4 mkg.
