Revotron 1.2T
6
F.
TIGHTENING TORQUE SPECIFICATIONS :
Fastener
Fastener Type and
Size
Torque
(Kgfm)
(Nm)
Main Bearing Cap Bolts
M10 X 1.5
5.5
54
Cylinder head Bolts
M10 X 1.5
See Note 1
Spark plug to Cylinder Head
M12 X 1.25
1.5 to 2.5
15 to 25
Cylinder Head Cover to Cylinder Head
HEX.FL.Screw M6
0.8 to 1
8 to 9.81
Oil sump to Cylinder Block
HEX.FL.Screw M6
1
9.81
Sealing Plug For Oil Gallery, Block Rear
M14 X 1.5
3.5
34
Oil Sump Drain Plug
M12 X 1.5
3.5
34
Timing Cover Rear to Cylinder Block
HEX.FL.Screw M10
0.8 to 1
8 to 9.81
Timing Cover Rear to Cylinder Head
HEX.FL.Screw M8
0.8 to 1
8 to 9.81
Timing Cover Rear to Oil Pump
HEX.FL.Screw M6
0.8 to 1
8 to 9.81
Timing Cover Front (Bottom) to Oil Pump
HEX.FL.Screw M6
0.8 to 1
8 to 9.81
Timing Cover Front (Upper & Lower)
HEX.FL.Screw M6
0.8 to 1
8 to 9.81
Sealing Plug For Oil Gallery, Cylinder Head
Mc 10 X 1
2.5
25
Rear Cover Crankcase on Cylinder Block
Screw M6
1
9.81
Oil Filter Cap on Cylinder Head
-
1.2
12
Vacuum Pump on Cylinder Head
HEX.FL.Screw M6
1.5
15
Dipstick Tube to Cylinder Block
HEX.FL.Screw M8
2
20
PCV Valve Assembly to Cylinder Head Cover
-
0.18 to 0.29 1.7 to 2.9
Connecting Rod Bolt
M8 X 1
4.5
44
Flywheel on Crankshaft Flange Bolt
M10 X 1.5
5
49
Crankshaft Gear to Crankshaft Bolt
M14 X 1.5
4 +60
0
39 +60
0
Vibration Damper 5 Groove & A/C Pulley to
Crankshaft Gear
M8
2.5
25
Timing Belt Tensioner to Cylinder Block
HEX.FL.Bolt M10
4.5
44
Cam Thrust plate to Cylinder Head
Cap Screw M6
1
9.81
Timing Belt Idler to Cylinder Block
HEX.FL.Bolt M10
4.5
44
Camshaft Gear to CamShaft
HEX.Bolt M12
8
78
Rocker Nut on Rocker Arm Adjusting Screw
M9
2 to 2.5
20 to 25
Rocker Shaft to Cylinder Head
Screw M6
1
9.81
Fuel Rail on Intake Manifold
HEX.FL.SCREW M8
2
20
Injector Retainer on Fuel Rail
HEX.FL.Screw M5
0.5 to 0.6
5 to 6
Exhaust Manifold on Cylinder Head
Clinch Nut M8 X 1.25
1.9 to 2.1
19 to 21
Intake Manifold on Cylinder Head
Clinch Nut M8 X 1.25
1.9 to 2.1
19 to 21
