ZEST AND BOLT - page 343

ENGINE 1.3L QUADRAJET (90PS)
6
Sr No. Fastner Location /
Fastener
Size
Tightening Torque
Description
Type
in Kg-m
30 Engine oil supply pipe to
Connector
M10
1.3 ~ 1.6
turbocharger
31 Exhaust gas/water heat exchanger
Bolt
M8
2.3 ~ 2.8
for E.G.R. system
32 Exhaust manifold
Nut (to be
M8
1.4 ~ 1.6 + 30° +/- 3°
replaced)
33 Glow heater plug
-
M8
0.9 ~ 1.1
34 Injector brackets
Nut
M8
1.8 ~ 2.2
35 Intake manifold
Bolt
M8
2.3 ~ 2.8
36 Intermediate driveshaft bearing
Bolt
M8
2.0 ~ 2.4
support
37 Moving timing system tensioner
Bolt
M6
0.8 ~ 1.0
38 Pipe from pressure pump to fuel
Connector
M14
2.6 ~ 2.9
manifold - fuel manifold side
39 Pipe from pressure pump to fuel
Connector
M12
2.3 ~ 2.5
manifold - pressure pump side
40 Pipes from fuel manifold to injectors Connector
M14
2.6 ~ 2.9
- fuel manifold side
41 Pipes from fuel manifold to injectors Connector
M12
2.3 ~ 2.5
- injectors side
42 Pressure pump
Bolt
M7
1.4 ~ 1.7
43 RPM sensor
Bolt
M6
0.8 ~ 1.0
44 Starter motor
Bolt
M8
2.25 ~ 2.75
45 Switch for engine oil pressure
-
M14
2.9 ~ 3.5
warning light
46 Thermostat
Screw
M8
2.2 ~ 2.7
47 Timing side power unit rigid support
Bolt
M10
5.7 ~ 6.3
to engine block
48 Crank pulley (Flange Bolt)
Bolt
M12
4.7 to 5.2 +75
0
+/- 3
0
49 Turbocharger to exhaust manifold
Nut
M8
2.2 ~ 2.7
50 Vacuum pump
Bolt
M8
1.8 ~ 2.2
51 Water pump
Nut
M6
0.8 ~ 1.0
