ENGINE 1.3L QUADRAJET (90PS)
5
3A.1.1.2 TIGHTENING TORQUES
Sr No. Fastner Location / Fastener Size Tightening Torque
Description Type in Kg-m
1 Alternator Bolt M8x1, 25x85 2.0 ~ 2.2
2 Alternator-power Bolt M8x1,25x45 2.0 ~ 2.2
steering pump mounting
3 A Mount Bolt M12 7.8
4 Auxiliary drive belt fixed
tensioner Bolt M8 2.2 ~ 2.7
5 Auxiliary drive belt moving
tensioner Bolt M10 4.5 ~ 5.5
6 B Mount Nyloc Nut M12 7.8
7 Bracket joining manual
gearbox/differential to engine Bolt M8 2.7 ~ 3.3
8 Cam angle sensor Bolt M6 0.64 ~ 0.96
9 Camshaft gears Bolt M12 13.5 ~ 16.5
10 C Mount Bolt M12 7.8
11 Compressor Bolt M8x1,25x80 2.0 ~ 2.4
12 Compressor support Bolt M8x1,25x35 2.0 ~ 2.4
13 Connecting rod caps Bolt M8 1.9 ~ 2.1 + 40° +/- 2°
14 Connecting rod caps Bolt M8 1.9 ~ 2.1 + 40° +/- 2°
15 Crankcase Central Bolt M10 1.9 ~ 2.1 + 80° +/- 3°
16 Crankcase Side Bolt M8 2.9 ~ 3.2
17 Crankcase Central Bolt M10 1.9 ~ 2.1 + 80° +/- 3°
18 Crankcase Side Bolt M8 2.9 ~ 3.2
19 Crankshaft oil seal front cover Bolt M6 0.8 ~ 1.0
20 Crankshaft oil seal front cover Nut M6 0.8 ~ 1.0
21 Cylinder head Bolt M10 3.8 ~ 4.2 + 90° + 90°
22 Engine cylinder head extension Bolt M8 2.5
23 Engine cylinder head extension Bolt M7 1.8
24 Engine oil filter mounting Bolt M6 0.8 ~ 1.0
25 Engine oil jet Bolt M6 0.8 ~ 1.0
26 Engine oil recovery manifold Bolt M6 0.8 ~ 1.0
27 Engine oil return pipe from
turbocharger Bolt M6 0.8 ~ 1.0
28 Engine oil sump - lower engine
crankcase side Bolt M6 0.8 ~ 1.0
29 Engine oil sump - timing cover side Nut M6 0.8 ~ 1.0
