CLUTCH RELEASE SYSTEM
7
7. REMOVAL
OF
CLUTCH
CONTROL
BRACKET
1. Remove dashboard lower from driver side.
2. Remove Electrical connection from stop light
switch.
3. Remove Split pin & washer to disconnect
brake pedal from brake booster assembly.
NOTE
Ensure to put the washer while assembly.
4. Remove clevis pin to separate booster
assembly from brake pedal.
5. Remove mountings screw M6 & take out stop
light switch with bracket.
6. Remove
Electrical
connection
from
contactless clutch sensor.
