6F33 TRANSAXLE
30
18. Remove bolting (six no.s) of flex plate to
converter from starter motor opening.
19. Disconnect ‘C’ mount bracket.
20. Remove ‘B’ mount Arm mounting on vehicle.
21. Remove the mounting bolts and take out the
transaxle along with torque converter from
Vehicle using proper stand.
NOTE:
Torque converter is axially free, so proper care
should be taken while removing Transmission
with Torque converter.
After Transaxle removal, torque converter should
be locked by tool 541258900632.
22. Lift and support the engine assembly properly
using engine holding stand (2871 5890 3211)
on vehicle.
23. Take out Gear Box from Vehicle using proper
stand.
