172 / 745
KRYOTEC ENGINE
164
25. Remove the bolt (1a) and disconnect the
turbocharger oil return tube (1b) from the
turbocharger.
26. Remove the bolt (1) and the oil level indicator
tube.
27. Remove the bolts (2a) and the exhaust
manifold and turbocharger (2b).
28. Remove the exhaust manifold gasket.
29. Remove the bolt (1) from the oil vapor recovery
pipe.
30. Remove the bolts (2) from the oil vapor
recovery pipe.
31. Remove the bolts (1a) and the oil vapor
separator (1b) with the oil vapor recovery pipe
attached.
