P130024:- Output Voltage High
Overview:
ISO Code (If applicable)
P130024
Customer Symptom
NA
Fault Effect (On Vehicle)
-
Lamp Status (If Any)
NA
DTC Detection Condition
This DTC gets logged if the output voltage is higher than 16V
Normal Operating Condition
If the output voltage is less than 16V
.
Probable Trouble Area
1.
Wrong LV battery connected
2.
Secondary feedback loop fault
3.
Sensor error
Healing Condition
Ignition OFF wait till VCU sleeps & Ignition ON
Write up for
the system:-
HV DCDC Converter converts DC high voltage to low voltage to charge 12V battery. The conversion starts with wakeup
and enable signal to DCDC converter from VCU.
Pre-Check Points:
a)
Check for design intended LV Battery
b)
Check LV Battery voltage
c)
Check the DC output connector for damage
LV Signal Connector
HV Battery
DCDC Converter
12V LV Battery
