P22E202:- Wakeup output signal error
Overview:
ISO Code (If applicable)
P22E202
Customer Symptom
NA
Fault Effect (On Vehicle)
OBC will stop charging HV battery
Lamp Status (If Any)
NA
DTC Detection Condition
Wake up signal is stuck
Normal Operating Condition
Wakeup signal in spec range
Probable Trouble Area
1. Software issue in OBC.
Healing Condition
Disconnect the gun and connect back after VCU sleep
Write up for
the system:-
The on-board charger (OBC) takes AC input and converts it to direct current to charge a HV battery. The LV supply of OBC
is from 12V battery. It requires AC HV supply voltage of 230V, 50Hz to charge the HV battery.
.
Pre-Check Points:-
KL 30
12V LV supply to OBC
KL 31
LV/Chassis ground to OBC
a) Check for proper terminal connection of 12V LV Battery
b) Check for 12V LV Battery Voltage is with in the range ( 7.5V to 14V)
TroubleShooting:-
Flow Diagram or table format for diagnosing the fault code
Step no
.
Description
Check Point
if YES
if NO
1
Connect the Charging Gun & switch ON
the AC supply. check for the fault code.
Fault code P22E202
is present?
Replace OBC.
Repair complete.
On-Board charger
230V AC supply
HV Battery
LV signal connector
