NEXON EV
X114H
DTC Troubleshooting Data
Version: 3.0
Date: 27-May-2020
`
40
Author: K Tejaswini Manasa/ Navya Krishnan/Gaurav Jha
Copyright © TATA MOTORS Ltd.
This document must not be used in anyway, such as copying and redistributing to third parties, without the consent of author.
P229241:- Internal SCI communication CRC failure
Overview:
ISO Code (If applicable)
P229241
Customer Symptom
NA
Fault Effect (On Vehicle)
OBC will stop charging HV battery
Lamp Status (If Any)
NA
DTC Detection Condition
OBC internal CRC in CAN communication failure
Normal Operating Condition
SCI communication is normal
Probable Trouble Area
1. CAN transceiver in OBC is failed.
2. DSP in OBC is failed.
3. Program bug in OBC
Healing Condition
Disconnect the gun and connect back after VCU sleep
Write up for
the system :-
The on-board charger (OBC) takes AC input and converts it to direct current to charge a HV battery. The LV supply of OBC is
from 12V battery. It requires AC HV supply voltage of 230V, 50Hz to charge the HV battery. Without the LV supply charging
is not possible. OBC communicates with HV battery through BMS.
Pre-Check Points:
KL 30
12V LV supply to OBC
KL 31
LV/Chassis ground to OBC
a) Check for 12V LV Battery Voltage is with in the range ( 7.5V to 14V)
TroubleShooting:-
Flow Diagram or table format for diagnosing the fault code
Step no
.
Description
Check Point
if YES
if NO
1
Connect the Charging Gun & switch ON
the AC supply. check for the fault code.
Fault code P229241
is present?
Replace OBC.
Repair complete.
On-Board charger
230V AC supply
HV Battery
LV signal connector
