TRANSAXLE TA6300
41
10. Press deep groove ball bearing on lay shaft
by using drift part no 2870 5890 3256.
11. Tighten the locking screw of lay shaft.
12. Press cylindrical roller bearing outer race on
housing front half-using drift part no 2870
5890 3256.
C. DIFFERENTIAL DISASSEMBLY:
1. Remove Outer race & Inner race of differential
side taper bearing with the help of puller 5412
5890 2601 & spacer 2702 5890 2612 along
with shims.
2. Remove Outer race taper bearing of
differential from front & rear housing with the
help of puller 5438 5980 2603.
