1.5L REVOTORQ ENGINE

208

b) On exhaust manifold

PIN

DESCRIPTION

1

(+) Signal, Grey

2

(-) Ground, White

xx. DPS SENSOR

SENSOR LOCATION

CONNECTOR DETAIL
