1.2L REVOTRON ENGINE
23
Cylinder Block
Note:-
•
This Symbol indicates critical tightening torque.
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1
Seal Plug M20x1.5 for oil gallery
crankcase
3.5
2 Crankcase
3 Knock Sensor
4 Hex Flange Screw M8X30
2.0 ± 0.5
5 Sealing Plug M24X1.5
3.5
6 Crankshaft Oil Seal (Rear)
7 Hex Flange Bolt M8X70 (10 Qty)
3.2
8 Bed plate MB bolt M10 (8 Qty)
•
1) 5.0 ± 0.5
2) 120° ± 15°
9 Bed Plate
10 Crank Angle Sensor
11
Hex Flange Screw M6X22 for Crank
Angle Sensor
12 Deflector Plate Cyl. Block
13 Hollow Dowel,12H6 x10.6 x 12L
14 Hex Flange Bolt M8x35
•
1.0 ± 0.1
45° ± 5°
15 Balancer Mass
16 Cylindrical Pin
17 Balancer Shaft
18 Thrust Washer
19 CSK Socket Screw M6x20 (2 Qty)
20 Gear, Balancer Shaft
21 Hex Flange Bolt M12x45
•
5.0 ± 0.5
45° ± 5°
