1.5L REVOTORQ ENGINE
29
Exhaust manifold, Catcon, Turbocharger
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Turbocharger Assy.
02
Gasket, TC Intake To Exhaust Manifold
03
Sensor Temperature Exhaust Manifold
4.5 ± 0.5
04
H/Fl Screw M8x18 (Qty. 2)
1.5
05
Bracket, Wiring Harness Mtg -
06
Temperature Sensor
4.5 ± 0.5
07
Lambda Sensor
5 ± 0.5
08
Temperature Sensor
4.5 ± 0.5
09
H/Fl Screw M8x16 (Qty. 2)
2 + 0.3
10
Support Bracket, CCC Assy RH Side
11
Hose Clamp (Qty. 3)
12
Hose, DPF Intake Pressure, Sensor Side
13
Bracket Assy (DPS Mtg.)
14
DPS Sensor -
15
Heat Shield, DPS Sensor
16
Hex Fl Scr M6x35
0.8
17
Hose Clamp
18
Hose, DPF Outlet Pressure, Sensor Side
19
Flanged Clinch Nut (Qty. 3)
3.0
20
LNT+DPF Assy -
21
H/Fl Screw M8x25
2 + 0.3
22
Lambda Sensor
23
Heat Shield Assy, Exhaust Manifold, Top
24
Flanged Clinch Nut (Qty. 10)
2 + 0.3
25
Exhaust Manifold
