DRIVESHAFT
6
8. ON VEHICLE ASSEMBLY OF DRIVE
SHAFT (LH & RH SIDE)
1. Install the Drive shaft into Knuckle End.
2. Install the Drive shaft into Transaxle End.
3. Insert the LCA ball joint in knuckle & tighten
the mounting fastener with torque 5.5 Kg-m.
4. Insert the steering Link ball joint into knuckle
& tighten the nyloc nut with torque 7 ± 0.5
kgm.
5. By Using allen Key and Connect Upper ARB
Link onto the Front Strut.
6. Apply Brake and Tighten Drive shaft Lock
Nut.
7. Fix Mud liner front RH.
8. Position wheel and tighten the front wheels
Nuts.
