ELECTRICAL
31
even if the actual INST FE is higher than 30 km/l.
For MPG setting, the indicated maximum value of INST FE is
80 MPG. No more than 80 shall be indicated on the display
even if the actual INST FE is higher than 80 MPG.
6
DEF Gauge
When the ignition switch is in “ON” position, DEF gauge gives
an approximate indication of the amount of DEF in the fuel
tank. “F” stands for full and “E” stands for empty.
When DEF in the tank is near to empty position, low DEF level
warning Telltale turns on in Amber. Refill the tank as soon as
possible.
7
TPMS
TPMS (Tire Pressure Monitoring System) shows the
pressure/temperature of respective tire.
When tire temperature of any tire will be high then the “HI”
indication for respective tire instead of temperature value will
be displayed for 4 sec. Rest all tires will have respective
temperature value along with unit for 4 sec then the pressure
for respective tire will be displayed.
Similarly, When tire pressure of any tire will be high/low then
the “HI”/”LO” indication for respective tire instead of pressure
value will be displayed for 4 sec. “AL” will be displayed for
respective tire having Air Leakage.
“--” will be displayed for respective tire having sensor missing
or malfunction fault.
For any of the above warning respective tire on display will be
in blinking state.
NOTE: If any of the warning is displayed, it means ‘Fault’
condition. In such case, take vehicle to air station to maintain
the desired pressure level.
8
Clock
Indicates current time in AM/PM mode. Clock time can be
changed using ‘SET’ & ‘MODE’ knob.
12/24 hr format can be changed using MODE button.
Whenever the battery terminals or related fuses are
connected, you must reset the clock time. This feature is
available when ignition switch is in ON’ position.
NOTE: Clock settings can also be changed through
infotainment system
9
Outside
Ambient
Temperature
Displays outside ambient temperature in units °C or °F.
Resolution: 1 °C or °F
Note:
User can change the Temperature unit using SET and MODE
buttons and °F is applicable for Export variant only.
The temperature sensor is in the front bumper of the vehicle,
therefore the temperature reading can be affected by heat
reflection from the road surface, engine heat and the exhaust
from surrounding traffic. This can cause an incorrect
temperature reading when speed is under low speeds or when
stopped.
If display shows ‘- - ‘, take your car to TATA authorized service
Centre.
10
Service
reminder
Indicates the number of days or kilometers remaining for next
service at every ignition ON for few seconds if service is due.
If service is overdue, DIS will display 0 km or 0 days and
spanner symbol will blink at every ignition ON for few seconds.
DIS will indicate Spanner symbol as continuously ON when
