FATC
54
4. To access Blower from Driver side, Remove
steering column cover.
5. Remove one screw on blower Assembly.
6. Disconnect Electrical connection from Blower.
7. Disconnect the snap
8. Rotate Blower assembly by 20 degree in anti-
clockwise direction using special Tool part no.
9. After rotating the blower assembly by 20 degree
in anti-clockwise direction take out the blower
assy. from left side in shown direction.
ASSEMBLY
For assembly follow the reverse procedure of re-
moval
REMOVAL
1. Remove steering column cover.
2. Access the blower control module from driver
side. Remove the electrical connection from the
module.
3. Remove the mounting screws and take out the
module along with the cover.
REFITMENT
For fitment, follow reverse procedure of removal.
