562 / 745
FATC
53
5. Remove four mounting screws of control panel.
6. Disconnect Electrical connection from control
panel.
7. Take out the control panel.
REFITMENT
For fitment, follow reverse procedure of removal.
C. BLOWER MOTOR REMOVAL
LOCATION
It is located on the top side of the HVAC unit.
ON VEHICLE BLOWER MOTOR REMOVAL
1. Remove Glove Box. (Refer Body Draft.)
2. Disconnect Electrical connection from Actuator.
3. Remove three screws and take out Intake As-
sembly.
