911 / 1003
ELECTRICAL
88
3. Locking all doors
Pressing the Lock push-button (3) once.
Remote locks all the doors of the vehicle.
4
. Folding key blade IN / OUT
Press button (4) to flip out the key blade.
For folding, press the button (4) and fold the key
blade inside.
NOTE
Key Blade should not be fold without pressing the
button. In addition, it should not be force in any
direction apart from folding direction to avoid
damage to Flip Mechanism
Flip key Features
Vehicle search
In vehicle locked condition if lock button on
remote key is pressed the turn indicators of
vehicle flashes 4 times.
Automatic activation of immobilizer
If key is removed from ignition, the engine will be
immobilized automatically even if you forget to
lock the vehicle.
For few variant, Ignition off is required to
immobilize the vehicle.
Auto locking / unlocking of doors / auto relock
Vehicle doors get automatically locked when
all doors are closed and the vehicle speed
crosses 10 kmph. Please refer section starting
and driving for more information.
When ignition key is taken out all the doors,
get automatically unlocked.
For few variant, when ignition is turned off all
the doors get automati- cally unlocked.
Also, when unlocked with remote key and if no
door is opened within 30 sec- onds, vehicle doors
get automatically locked.
Anti-grab / anti-scan coding
The remote control set of this security system is
protected against the use of devices called
‘scanners‘ and ‘grabbers’ which can record and
reproduce some types of remote codes.
Sleep Mode
If remote key is not used for more than a week
then its functionalities will turn to sleep mode. In
such a case, to activate the remote key
functionalities, open the door mechanically with
the key blade.
NOTE
In case any button of the key is accidentally
pressed for more than 20 seconds, the remote
stops functioning till the time the button is
pressed. The LED on the Remote also stops
glowing. The function of the remote gets
reinstated immediately when the user stops
pressing the push button of remote.
2. SMART KEY
Keep the smart key with user to perform the
passive access. It is used for locking, unlocking
and starting the vehicle.
1. Locking all doors
2. Approach Light
3. Tailgate opening
4. Unlocking all doors
