ELECTRONIC STABILITY CONTROL INTEGRATED PROGRAM (ESCi)
14
1.5 TROUBLESHOOTING
The trouble shooting for ESCi is same as that for ABS system.
CAUTION
Calibrate the steering angle sensor whenever any suspension or steering related work is done and also
when wheel alignment is carried out.
In addition, if there is any fault related to ESCi components or system, the ESCi warning indicator on the
instrument panel will come ON.
B. TABLE OF ESCi - FALL-BACK LEVEL
ABS FALLBACK
LEVEL
ESCi LAMP
ABS WARNING
LAMP
BRAKE LAMP
HDC LAMP(If
Applicable)
HHC LAMP
Status
System
Syste
m
active
Lamp
System
active
Lamp
System
active
Lamp
System
active
Lamp
System
active
Lamp
System active with
limitation
YES
BLINKI
NG
YES
ON
YES
ON
NO
ON
NO
ON
System active
YES
BLINKI
NG
YES
OFF
YES
OFF
YES
ON
YES
OFF
Emergency - ABS
NO
NO
YES
OFF
YES
OFF
NO
NO
NO
NO
Emergency - EBD
NO
NO
NO
OFF
YES
OFF
NO
NO
NO
NO
System passive
NO
OFF
NO
OFF
NO
OFF
NO
OFF
NO
OFF
