TRANSAXLE TA6300 AMT
51
3. Remove Dowell sleeve heavy 6x40 as shown
4. Push spider from differential housing.
5. Rotate bevel pinions by 90
0
and remove the
bevel pinions.
6. Remove side bevel gears with washers.
7. Hold fixtures for gear on differential assembly
part no. 2702 5890 2609 in soft jaw vice.
8. Mount differential housing on fixture part no.
2702 5890 2609 and lock it.
9. Unscrew and remove the collared bolts (10
Nos.).
