1.5L REVOTORQ ENGINE
184
C. ELECTRONIC CONTROL UNIT (ECU)
ECU Description and Operating Conditions
Electrical Characteristics:
Minimum Cranking Voltage: 5.5V
Normal Operating Voltage: 10V to 16V
Operating Temperature: -40°C to 85°C
ECU Location
Electronic Control Unit (ECU) is mounted in
engine compartment.
Connector Detail
