NEXON BS VI - SERVICE MANUAL

27 / 1003

1.2L REVOTRON ENGINE
16
C. Cylinder Head Cover
 Cylinder Head Cover
No. DESCRIPTION
NO REUSESEALANT
LUBRICATION
TORQUE(Kgf.m)
1 Cover Assy., Cylinder Head
2 Ignition Coil (3 Qty.)
3 Hex Flange Bolt M6x25 (3 Qty.) 1.0 ± 0.2
4 Hex Flange Screw M6x22 (12 Qty.) 1.0
5 Hex Flange Bolt M6x40 (2 Qty.) 1.0
6 Solenoid Valve (2 Qty.)
7
Hex Flange Nut AM6• 1.0
8
Stud• 1.0
