1.5L REVOTORQ ENGINE
32
Cylinder head and Components
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Cylinder Head Cover
02
Hex. Flange Screw M6x25 (Qty. 17)
1.0
03
Hex. Bolt (Camshaft Brg. Cap) (Qty. 10)
1.5
04
Hex. Flange Bolt M6x35
1.5
05
Hex. Bolt (Camshaft Brg. Cap)
1.5
06
Camshaft Bearing Cap (Inner)
07
Camshaft Bearing Cap (Front)
08
Camshaft (Exhaust)
09
Camshaft (Intake)
10
Assy. Roller Finger Follower (Qty. 16)
11
Assy. Hydraulic Lash Adjuster (Qty. 16)
12
Valve Lock Half (Qty. 32)
13
Valve Spring Retainer (Qty. 16)
14
Spring Valve (Qty. 16)
15
Seal, Valve Guide (Qty. 16)
16
Spring Seat (Qty. 16)
17
Cylinder Head
18
Glow Plug (Qty. 4)
0.9
19
Valve Guide (Qty. 16)
20
Valve Seat Insert Intake (Qty. 8)
21
Intake Valve (Qty. 8)
22
Exhaust Valve (Qty. 8)
23
Valve Seat Insert Exhaust (Qty. 8)
24
Washer (For Cyl. Head Bolt) (Qty. 10)
