234 / 1003
1.5L REVOTORQ ENGINE
30
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
26
Gasket, Exhaust Manifold
27
Heat Shield Assy, Turbocharger
28
Hex Fl Scr M8x22 (Qty. 2)
3.0
29
Gasket (TC Outlet To CAT. CON.)
30
Flanged Clinch Nut (Qty. 3)
3.0
31
H/Fl Bolt M8x28 (Qty. 2)
2.0
32
Bracket Turbocharger Support
33
Support Bracket, Turbocharger (Turbo
Support)
