221 / 1003
1.5L REVOTORQ ENGINE
17
Lubrication system
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Gasket (Oil Pump)
02
Assembly, Oil Pump
Both Side
03
Hex_Screw_M6x1x25 (Qty. 9)
1.0 + 0.2
04
Crankshaft Oil Seal (Front)
05
Gasket, Oil Pump Strainer
06
Oil Pump Strainer
07
Stud_Cm6x16 (Qty. 2)
08
Clinch Nut (Qty. 2)
1.0 + 0.2
09
Oil Sump (Upper) Aluminium
10
Hex. Flange Screw M6x22 (Qty. 20)
0.8
11
Oil Sump (Lower)
12
Sealing Washer (Oil Sump Drain Plug)
13
Magnetic Drain Plug M16x1.5
3.5
14
Hex. Flange Screw M6x14 (Qty. 20)
0.8
15
Hex Flange Bolt M6x121.5 (Qty. 2)
0.8
16
Gasket, Piston Cooling Nozzle (Qty.4)
17
Nozzle Assembly, Piston Cooling Piston
Cooling (Qty.4)
18
Cap Screw M5x10 (Qty.4)
0.8
19
Hex_Screw_M8x25 (Qty.2)
2.0
20
Housing Water Inlet Elbow
21
Gasket (Water Inlet Elbow)
22
Oil Filter Assy. (Tc)
Apply
on rubber
ring
