218 / 1003
1.5L REVOTORQ ENGINE
14
Intake Manifold and Fuel Injection System
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Intake Manifold Assy
02
Gasket (Intake Manifold)
03
Flanged Clinch Nut (2 Qty.)
2 + 0.3
04
EGR Module Assy
05
Gasket, EGR Pipe
06
Egr Pipe Assy, Cooler To Charge Air Pipe
07
A/H Scr M6x20 (2 Qty.)
1.3 + 0.2
08
Hex Fl Nut Bm6 (2 Qty.)
1 + 0.2
09
Cap Screw M6x45 (3 Qty.)
0.8
10
Throttle Valve Assy, Intake
11
Gasket, Air Intake, Throttle Body -
12
Sensor, Air Temperature
13
Hex Fl Screw M6x16
0.8
14
Elbow, Air Intake
15
Hex Fl Nut Bm6 (4 Qty.)
1 + 0.2
16
Gasket, Intake Manifold To Intake Pipe
17
Cap Screw M8x35 (3 Qty.)
2 + 0.3
18
Cap Screw M8x22 (4 Qty.)
2 + 0.3
19
Hex Fl Screw M6x16
1 + 0.2
20
Hex Fl Nut Bm6
2 + 0.3
21
Gasket, EGR Pipe
22
Injector Assy (4 Qty.)
23
Pin (Injector Claw Support) (4 Qty.)
24
Claw, Injector 19 Mm Dia (4 Qty.)
25
Sph. Washer (Injector Claw) (4 Qty.)
