1.2L REVOTRON ENGINE
34
Air Intake System :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Air Filter Housing Assembly
2 Clamp
0.5
3 Hose Clamp
0.5
4 Hose, Air Filter To Throttle body
5 Filter Element
6 H/FL Bolt M8x35
7 Washer
8 Sealing Rivet
9 Snorkel Assy
10 Grommet, Air Filter
11 Hose, Blowby
12 Spr. BD Clamp 27dx12w
13 Detachable plate
14 Support plate
15 Hex FL Screw M8x14
2
16 Hex Nut M8
