1.5L REVOTORQ ENGINE
181
OUTPUT CHARACTERISTIC
CONNECTOR DETAILS
PINOUT DETAILS
Pin No
Description
1
Supply +
2
Supply +
3
GND Supply -
4
Analog Signal
5
GND Supply -
6
Analog Signal
viii. WATER IN FUEL SENSOR
It Measures water percentage in fuel and gives
indication on the instrument cluster. The water
collected to be drained when the indicator glows
in Instrument panel
