331 / 1119
1.5L REVOTORQ ENGINE
143
12. Remove all the upper main bearing half shell.
13. Remove the thrust washer upper half.
14. Remove
Allen screws and take out all piston
cooling nozzles.
xi. PISTON
CONNECTING
ROD
DISASSEMBLY
1. Remove piston pin circlip with suitable plier.
2. Remove piston pin from the piston by pushing
it out using a soft drift
3. Remove the connecting rod
