1.2L REVOTRON ENGINE
20
Cylinder Head-A :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1
Hex FL Bolt M6X60 for ITG Bearing Cap Upper
(4 Qty)
•
1.5±0.15
2
ITG Bearing Cap Upper
3
Camshaft
4
ITG Bearing Cap Lower
5
Cylinder Head
6
Exhaust Valve
7
Intake Valve
8
Camshaft Bearing Cap (Inner)
9
H/FL Bolt M6X35 for Camshaft Brg. Cap (12 Qty)
•
1.5
10
Dowel Bolt M6X35 for Camshaft Brg. Cap (12 Qty)
•
1.5
11 Spring Seat
12 Valve Guide Seal
13 Valve Spring
14 Valve Spring Retainer
15 Lock Half
16 HLA RFF Assembly
Note:-
•
This Symbol indicates critical tightening torque.
