1.2L REVOTRON ENGINE
16
Intake Manifold :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 ETC to Intake Manifold (Hex Nut AM6) (4 Qty)
1 + 0.2
2 ETC to Intake Manifold (STUD CM6X45) (4 Qty)
1 + 0.2
3 Electronic Throttle Control
4 Gasket (For Electronic Throttle Control)
5 MAP Sensor
6 Hex FL Screw M6X10
0.8
7 Intake Manifold
8
Self-Locking Nut (Clinch Nut M8 X 1.25) (4 Qty)
•
2.0+0.3
9 M8X30 at bottom of intake manifold on block (1 Qty)
2.5
10 Grommet on intake manifold (Bottom)
11 Gasket (Intake Manifold) (3 Nos)
12 Intake Manifold Stud
2.5
Note:-
•
This Symbol indicates critical tightening torque.
