1.5L REVOTORQ ENGINE
50
4. Remove the fuel line connections (Quick fit
Connectors) to the fuel filter.
5. Pry out harness rivets on mounting bracket.
6. Remove Hex FL screw mountings on Filter
Assy.
7. Push the fuel filter in upward direction and
take it out from the groove in mounting
bracket.
INSTALLATION
1. Place the fuel filter in the mounting bracket.
Be sure to orient the fuel filter in the proper
direction.
2. Press the fuel filter in downward direction and
fit it on the groove in mounting bracket.
3. Connect the fuel lines to the filter, making
sure the lines are secure.
4. Make electrical connection to the fuel filter.
5. Lower down the vehicle from hoist
6. Start the engine and inspect the connections
for leaks. Stop the engine immediately and
repair if any leaks.
