WHEELS AND TYRES
12
Following precautions should be taken while
balancing wheel:
Deposits of mud, dust etc. must be cleaned
from inside of the rim.
Remove stones from tread, clean the tyre and
rim before balancing to achieve better results.
Each tyre should be inspected for any
damage.
Do not use more than one balance weight on
one side.
Use coated weights on aluminum wheels/rims
to prevent damage to the finish.
The type of balance weights, when used, must
be in accordance with the profile of the rim
flange.
NOTE
For balancing wheel, follow the manufacturer’s (of
balancing machine) manual for balancing
instructions, recommendations and any other
additional information.
III.
TYRE ROTATION
To equalize wear rotate the tyres as per to the
figure given below periodically. Tyre rotation is
recommended for achieving identical wear on
each tyre. Regular rotation of tyres will also
prevent abnormal wear. The sketch indicates a
suggested sequence of tyre rotation. Rotate tyre
at a point specified in the service schedule.
NOTE
The tyre rotation should always be done including
the spare wheel. Spare wheel can be excluded
from rotation in the following conditions
If the spare wheel is damaged and not
recommended for normal use.
If the spare wheel size is different from the
normal tyres.
For 165/80 R14 TYRES
For 195/55 R16 AND 185/60 R16 TYRES
WITH TEMPORARY SPARE WHEEL
