1.2L REVOTRON ENGINE
31
J. Exhaust Manifold :
Exhaust Manifold :
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Exhaust Manifold
2 Gasket (Exhaust Manifold))
3 Stud C M8X25 for Exhaust (4 Qty)
2.5
4 M8X1.25 Flange P/T Nut. (4 Qty)
2.0+0.3
5 Lambda Sensor
5.0+1.0
6 Lambda Sensor
5.0+1.0
7 H/FL Screw M8X20
2.5
