1.2L REVOTRON ENGINE

26



Oil Sump

No.

DESCRIPTION

NO REUSE

SEALANT

LUBRICATION

TORQUE

(Kgf.m)

1 Oil Sump

2 Sealing Washer

3 Drain Plug

3.5

4

H/FL Screw M6X14 for Oil Sump (18

Qty)

1.0

5 Pipe seal

6 Water Bypass Assembly

7 H/FL Screw M6X14

1.0
