ELECTRICAL
61
TELL TALES
COLOR
INDICATOR
REMARKS
Check Engine
Amber
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. Illuminates continuously if a fault arise in Engine
Management System. Contact TATA MOTORS Authorized
Service Centre.
Immobilizer
Red
1. Illuminates when the system disables engine start if the
original key is not used.
2. Bulb blinks: vehicle is in immobilized condition when key
is not inserted.
3. Bulb ON: Problem with key/system. Contact TATA
MOTORS Authorized Service Centre.
Water in fuel
(Only
for
Diesel)
Amber
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. Illuminates continuously if excess water is accumulated
in the fuel filter. Contact TATA MOTORS Authorized
Service Centre to drain the water immediately to avoid
serious damage to the fuel injection system.
Diesel
Pre-
Heat indicator
/Glow
Plug
Indicator (Only
for Diesel)
Amber
This symbol comes ‘ON’ when the ignition key is in the ‘ON’
position. Engine should be started only after this indicator
goes ‘OFF’
Speed
Limit
bulb
Amber
This symbol comes ON when vehicle speed is more than
120 kmph. This symbol blinks and audible buzzer sounds
simultaneously when Vehicle Speed is more than 120
kmph. At this stage, reduce the vehicle speed.
Diesel
Particulate
Filter
bulb
(Only
for
Diesel)
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after the engine starts. This symbol comes
ON when Diesel Particulate filter in exhaust system is
malfunctioning. At this stage, take the car to the nearest
Authorized Service outlet.
CNG Bulb (PP)
Amber
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after 4 seconds. This symbol comes ON
when CNG fuel mode is activated.
DRL Lamp
Green
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after 4 seconds. This symbol comes ON
when the Day Time Running lamp is ‘ON’.
AMT
Fault
Indicator
Amber
When ignition is turned ‘ON’, this symbol comes ‘ON’ for
four seconds and goes ‘OFF’. This symbol shall continue to
remain 'ON' or shall come 'ON' after Ignition On precheck if
there is a problem in the AMT system.
CITY (PP)
Blue
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after 4 seconds. This symbol comes ON
when CITY driving mode is activated (if applicable).
